UNS N10276 Stainless Steel Round Bar Hastelloy C276 Pipes Bright

Name: UNS N10276 Stainless Steel Round Bar Hastelloy C276 Pipes Bright
Brand: BAO STEEL
Price: 30 USD

Wholesale UNS N10276 Stainless Steel Round Bar Hastelloy C276 Pipes Bright from china suppliers

Brand Name : BAO STEEL

Model Number : C276

Certification : ISO,SGS

Place of Origin : China

MOQ : 1 Ton

Price : 30 - 40 USD/Kg

Payment Terms : L/C, T/T

Supply Ability : 500 tons

Delivery Time : 7 days

Packaging Details : export packing

Product name : C276 round bar

Alloy Or Not : Non-alloy

Surface treatment : polished

Tolerance : 0/+1mm

Length : 2000-6000mm

Technology : Clod Drawn

Contact Now

Bright Polished Hastelloy C276 Round Bar / Stainless Steel Bright Bar Diameter 4 - 100mm

Specification of our hastelloy C276 round bar

Products Name	Hastelloy C276 round bar
Finishing	Hot rolled / Cold Drawn
Diameter	hot rolled bars: 10 - 250mm
Diameter	cold drawn bars: 4 - 60mm
Length	6m or cutting any length as request
Standard	ASTM EN
MOQ	100 kgs
Packing	surround by waterproof paper and plastic foil
Loading Port	Shanghai Port(China)
Certificate	EN 10204-3.1 / CO or other certificate as request
Other Grade	Stainless steel: 201 303 304 310S 316L 321 2205 2507 410 420.etc Monel: 400 500 Inconel 600 625 800 825.etc

Hastelloy C276 - UNS N10276 Advanced Nickel Alloy

Hastelloy C276 is a nickel-molybdenum-chromium superalloy with an addition of tungsten designed to have excellent corrosion resistance in a wide range of severe environments. The high nickel and molybdenum contents make the nickel steel alloy especially resistant to pitting and crevice corrosion in reducing environments while chromium conveys resistance to oxidizing media. The low carbon content minimizes carbide precipitation during welding to maintain corrosion resistance in as-welded structures. This nickel alloy is resistant to the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process application in an as welded condition.

Although there are several variations of the Hastelloy nickel alloy, Hastelloy C-276 is by far the most widely used.

Alloy C-276 is widely used in the most severe environments such as chemical processing, pollution control, pulp and paper production, industrial and municipal waste treatment, and recovery of sour natural gas.

In what forms is Hastelloy C276 Available at Mega Mex?

Bar
Sheet
Plate
Pipe & Tube – welded and seamless
Fittings
- Elbows, tees, stub-ends, returns, caps, crosses, reducers, pipe nipples. etc.
Welding Wire (AWS Classifications: ERNiCrMo-4 and ENiCrMo-4)

Corrosion Resistant Hastelloy C276

Considered one of the most versatile corrosion resistant alloys available, Hastelloy C-276 exhibits excellent resistance in a wide variety of chemical process environments including those with ferric and cupric chlorides, hot contaminated organic and inorganic media, chlorine, formic and acetic acids, acetic anhydride, seawater, brine and hypochlorite and chlorine dioxide solutions. In addition, alloy C-276 resists formation of grain boundary precipitates in the weld heat affected zone making it useful for most chemical processes in the as-welded condition. This alloy has excellent resistance to pitting and stress corrosion cracking.

What are the characteristics of Hastelloy C276?

Excellent corrosion resistance in reducing environments
Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
High nickel and molybdenum contents providing good corrosion resistance in reducing environments
Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
Resistance to localized corrosion such as pitting and stress-corrosion cracking
One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide

Chemical Composition, %

Ni	Mo	Cr	Fe	W	Co	Mn	C	V	P	S	Si
Remainder	15.0-17.0	14.5-16.5	4.0-7.0	3.0-4.5	2.5 max	1.0 max	.01 max	.35 max	.04 max	.03 max	.08 max

In what applications is Hastelloy C-276 used?

Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings
Flue gas desulfurization systems
Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping
Sour gas wells
Pulp and paper production
Waste treatment
Pharmaceutical and food processing equipment

Fabrication with Hastelloy C-276

Hastelloy C-276 alloy can be forged, hot-upset and impact extruded. Although the alloy tends to work-harden, you can have it successfully spun, deep-drawn, press formed or punched. All of the common methods of welding can be used, although the oxyacetylene and submerged arc processes are not recommended when the fabricated item is for use in corrosion service.

Hastelloy C-276 Welding Material

Alloy C276 welding products are used as matching composition filler material for welding C276 alloy wrought and cast products, for dissimilar welding applications including other nickel-chromium-molybdenum alloys and stainless steels, and for weld overlay or cladding of steels.

Specifiacations: ASME-SFA-5.14 ERNiCrMo-4

Forms of C276 Filler Metal Available at Mega Mex

.031 in or .8 mm in diameter
.035 in or .9 mm in diameter
.039 in or 1.0 mm in diameter
.045 in or 1.1 mm in diameter
.047 in or 1.2 mm in diameter
.062 in or 1.6 mm in diameter
.078 in or 2.0 mm in diameter
.093 in or 2.4 mm in diameter
.125 in or 3.2 mm in diameter

ASTM Specifications

Pipe Smls	Pipe Welded	Tube Smls	Tube Welded	Sheet / Plate	Bar	Forging	Fitting	Wire
B622	B619	B622	B626	B575	B574	B564	B366

Mechanical Properties

Typical Room Temperature Tensile Properties of Annealed Material

Product Form	Tensile (ksi)	.2% Yield (ksi)	Elongation %
Bar	110.0	52.6	62
Plate	107.4	50.3	67
Sheet	115.5	54.6	60
Tube & Pipe	105.4	45.4	70
