500 Seamless Carbon Steel Plate SSAB Wear Resistant 12mm

Name: 500 Seamless Carbon Steel Plate SSAB Wear Resistant 12mm
Brand: SSAB
Price: 2.85 USD

Wholesale 500 Seamless Carbon Steel Plate SSAB Wear Resistant 12mm from china suppliers

Brand Name : SSAB

Model Number : 500

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 100KGS

Price : 2.85 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 80000KGS

Delivery Time : 7 Working Days

Packaging Details : Wooden Pallet BOX

Width : 600-2500mm

Grade : 500

Technique : Hot Rolled

Type : Steel Plate

Standard : ASTM,AISI,JIS,DIN

Length : 1000-12000mm

Special use : High-strength Steel Plate,Wear Resistant Steel

Thickness : 0.5-100mm

Contact Now

500 Plates Specifications

Specifications for 500 Plates. If any specification is not mentioned here, please use the contact button for quick quote.

Item	Abrasion Resistant Plate
Material	500
Thickness	4-80mm
Width	500-3000mm
Length	1000-12000mm
Heat Treatment	N, Q+T
Surface Paint	EP, PE, HDP, SMP, PVDF

500 Plates Chemical Composition

Plate	thickness mm	04/13/13	(13)-32	(32)-40	(40)-80
C	max %	0.27	0.29	0.29	0.3
Si	max %	0.7	0.7	0.7	0.7
Mn	max %	1.6	1.6	1.6	1.6
P	max %	0.025	0.025	0.025	0.025
S	max %	0.01	0.01	0.01	0.01
Cr	max %	1	1	1	1.5
Ni	max %	0.25	0.5	1	1.5
Mo	max %	0.25	0.3	0.6	0.6
B	max %	0.004	0.004	0.004	0.004
CEV	typv	0.49	0.62	0.64	0.74
CET	typv	0.34	0.41	0.43

500 Plates Mechanical Properties

Hardness, HB	470-530
Yield Strength, ksi	190,000
Tensile Strength, ksi	225,000
Impact Properties @ -40° F, min	22 ft. lbs.

500 Plates Material Application

Conveyors
Dump Truck Bodies
Loading Buckets & Bulldozers

Chutes
Crushers

500 Plates Price List

Contact us or click on the below button to request a latest 500 Plates price list. dedicated to providing the world-class 500 Plates that cater to all your demands at very competitive rates.

500 Plates - Value Added Services

Material Testing:

Mechanical Testing Such as Tensile of Area
Hardness Test
Chemical Analysis – Spectro Analysis
Positive Material Identification – PMI Testing
Flattening Test
Micro and MacroTest
Pitting Resistance Test
Flaring Test
Intergranular Corrosion (IGC) Test

500 Seamless Carbon Steel Plate SSAB Wear Resistant 12mm

Documentation & Packaging:

Commercial Invoice including HS Code
Packing List including Complete Details
Certificate of Origin legalized
Material Traceability Records
Quality Assurance Plan (QAP)
Heat Treatment Charts
Material Test Certificates (MTC)
Guarantee Letter
NABL approved Laboratory Test Reports
