DIN 1.4477 X2CrNiMoN29-7-2 10 - 350mm Ss Round Bar

Brand Name : Mittel

Model Number : 1.4477

Certification : SGS ISO

Place of Origin : China

MOQ : 500KGS

Price : 5 USD/KG

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 50 Ton

Delivery Time : 7 days

Packaging Details : Export Packing

OD : 10 - 350mm

Length : 6m/pcs

Surface : Black and Bright

Type : Hot Rolled

Service : cutting, polishing

Standard : ASTM A276

Contact Now

DIN 1.4477 Stainless Steel Round Bar X2CrNiMoN29-7-2Stainless Steel Bar 10 - 350mm

EN 1.4477 stainless steel is a duplex stainless steel formulated for primary forming into wrought products. 1.4477 is the EN numeric designation for this material. X2CrNiMoN29-7-2 is the EN chemical designation.

It can have a fairly high tensile strength among wrought duplex stainless steels. In addition, it has a fairly low thermal conductivity and can have a moderately low ductility.

The properties of EN 1.4477 stainless steel include two common variations. This page shows summary ranges across both of them. For more specific values, follow the links immediately below. The graph bars on the material properties cards further below compare EN 1.4477 stainless steel to: wrought duplex stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on

Chemical composition(mass fraction)(wt.%) of the 1.4477

C Si
≤		 Mn
≤		 P
≤		 S
≤		 Cr Ni Mo Other
≤0.030 0.50 0.80-1.50 0.030 0.015 28.0-30.0 5.80-7.50 1.50-2.60 N 0.30-0.40
Cu ≤ 0.80

Mechanical properties / Mechanische Eigenschaften / Caracteristiques mecaniques of grade 1.4477

Yield
Rp0.2 (MPa)		 Tensile
Rm (MPa)		 Impact
KV/Ku (J)		 Elongation
A (%)		 Reduction in cross section on fracture
Z (%)		 As-Heat-Treated Condition Brinell hardness (HBW)
165 (≥) 198 (≥) 21 34 14 Solution and Aging, Annealing, Ausaging, Q+T,etc 144

Grade informations

Grade : X2CrNiMoN29-7-2
Number: 1.4477
Classification: Austenitic-ferritic stainless steel - special grade
Density: 7.7 g/cm ³
Standard:
EN 10088-2: 2005 Stainless steels. Technical delivery conditions for sheet/plate and strip of corrosion resisting steels for general purposes
EN 10088-3: 2005 Stainless steels. Technical delivery conditions for semi-finished products, bars, rods, wire, sections and bright products of corrosion resisting steels for general purposes
EN 10297-2: 2005 Seamless circular steel tubes for mechanical and general engineering purposes. Stainless steel. Technical delivery conditions
EN 10088-1: 2005 Stainless steels. List of stainless steels
EN 10088-5: 2009 Stainless steels. Technical delivery conditions for bars, rods, wire, sections and bright products of corrosion resisting steels for construction purposes
EN 10088-4: 2009 Stainless steels. Technical delivery conditions for sheet/plate and strip of corrosion resisting steels for construction purposes
Equivalent grades: No information

DIN 1.4477 X2CrNiMoN29-7-2 10 - 350mm Ss Round BarDIN 1.4477 X2CrNiMoN29-7-2 10 - 350mm Ss Round BarDIN 1.4477 X2CrNiMoN29-7-2 10 - 350mm Ss Round Bar


Product Tags:

DIN 1.4477 ss round bar



6m ss round bar ASTM A276



10mm dia stainless steel bright bars


Wholesale DIN 1.4477 X2CrNiMoN29-7-2 10 - 350mm Ss Round Bar from china suppliers

DIN 1.4477 X2CrNiMoN29-7-2 10 - 350mm Ss Round Bar Images
