ASTM A240/A240M INOX 439 Metal Cold Rolled Stainless Steel Sheet SUS439 1.4510 2.5*1219mm

Name: ASTM A240A240M INOX 439 Metal Cold Rolled Stainless Steel Sheet SUS439 14510 251219mm
Brand: TISCO ZPSS LISCO BAO STEEL
Price: 1.25 USD

Wholesale ASTM A240/A240M INOX 439 Metal Cold Rolled Stainless Steel Sheet SUS439 1.4510 2.5*1219mm from china suppliers

Brand Name : TISCO ZPSS LISCO BAO STEEL

Model Number : 439

Certification : ISO MTC SGS

Place of Origin : China Jiangsu

MOQ : 50KGS

Price : 1.25-1.95 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 5000KGS

Delivery Time : 10 Days

Packaging Details : Wodden Pallet

Application : Construction,Kitchenware,Decoration,chemical

Width : 1000-2000mm

Type : stainless steel sheet

Standard : ASTM,JIS,AISI,EN

Length : 1000-6000mm or Customer's Requirement

Grade : 400 Series

Product name : 439 Stainless Steel Sheet

Surface : BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D

Thickness : 0.45-5mm

Edge : Mill Edge/ Slitting Edge Stainless Steel

Technique : Cold Rolled Finish

Price term : CIF CFR FOB EX-WORK

Item : ISO9001 Standard

Contact Now

ASTM A240/A240M INOX 439 Metal Sheet SUS439 Cold Rolled Stainless Steel Sheet 2.5*1219mm

Specifications	ASTM A240, ASME SA240
Dimensions	ASTM, ASME and API
Standard	JIS, AISI, ASTM, GB, DIN, EN, etc.
Surface	2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc.
Finish	Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc.

Grade Specifications for Stainless Steel 439 Sheets

Grade	WERKSTOFF NR.	UNS
SS 439	1.4510	S43035

Chemical Properties of SS 439 Sheets

Grade	Fe	Cr	Si	Ti	Mn	Ni	Mo	Nb/Cb	P	N	C	S
SS 439	81.3535	17.35	0.35	0.335	0.25	0.200	0.1	0.02	0.02	0.0100	0.01	0.0015

Mechanical Properties of SS 439 Sheets

Tensile strength (annealed)	438 MPa	63500 psi
Yield strength (annealed/ @strain 0.200 %)	263 MPa	38100 psi
Modulus of elasticity	GPa	ksi
Poisson’s ratio	0.270 – 0.290	0.270 – 0.290
Elongation at break (In 2″, 50% cold worked)	2.80%	2.80%
Hardness, Rockwell B (annealed)	72.9	72.9

439 STAINLESS STEEL ALLOY

UNS: S43900
EN-DIN: 1.4510

439 Oxidation resistance and corrosion resistance is superior to Type 409 in areas where temperatures may exceed the oxidation limit of Type 409 or where aqueous corrosion resistance, particularly to chlorides, is needed. Applications include: Tubular manifolds and other exhaust system with difficult to form exhaust components.

Nominal Composition

C:	0.070 max
Mn:	1.0 max
P:	0.040 max
S:	0.030 max
Si:	1.00 max
Cr:	17.00 – 19.00
Ni:	0.50 max
Ti:	>=0.20+4(C+N) – 1.10
Al:	0.15
N:	0.040
Fe:	BAL

Physical Properties
At 70°F (At 20°C)

Density
0.278 lb./in³ / (7685 kg/m³)

Modulus of Elasticity (E)
28.4 x 10³ ksi / (193 x 10³MPa)

Electrical Resistivity
24.0 μ ohm.in / (60.0 μ ohm.cm)

Applicable Specifications

ASTM A240

Typical Mechanical Properties – Typical Room Temperature Mechanical Properties

Typical mechanical properties are based on AK source, ASTM A240

Condition
Annealed

Tensile Strength (UTS)
66 ksi (455 MPa)

0.2% YS
43 ksi (296 MPa)

Elongation% in 2” (50.8 mm)
32%

Hardness Rockwell
74 HRBW

**The information and data in this product data sheet are accurate to the best of our knowledge and belief, but are intended for general information only. Applications suggested for the materials are described only to help readers make their own evaluations and decisions, and are neither guarantees nor to be construed as express or implied warranties of suitability for these or other applications. Data was obtained from our melt sources with data referring to mechanical properties and chemical analyses are the result of tests performed on specimens obtained from specific locations with prescribed sampling procedures; any warranty thereof is limited to the values obtained at such locations and by such procedures. There is no warranty with respect to values of the materials at other locations. Further information should be sought from the melt sources.
